Hog Heaven Mat

Product Number 421 (5/8" with black border), 422 (7/8" with black border), 423 (5/8" with striped border), 424 (7/8" with striped border)
Hog Heaven anti-fatigue mats are designed to provide comfort and durability in a variety of harsh conditions.
  • Comfortable - High-density nitrile-blended cushion helps eliminate pressure to the lower back and legs, providing superior comfort
  • Safe - Certified high-traction by the National Floor Safety Institute (NFSI); sloped edges provide a safe transition from floor to mat
  • Durable - Nitrile-blended cushion provides years of useful service life; cushion is molded, not glued, to the nitrile rubber surface so it will not separate; edges will not crack or curl
  • Versatile - Welding safe; ESD rating of electrically conductive; chemical resistant; surface is grease/oil proof and cushion is grease/oil resistant
  • Available in 5/8" or 7/8" thicknesses with solid black or with OSHA-approved caution yellow borders on two sides

Can be customized with your logo, design, or message (see Hog Heaven Impressions)

Hog Heaven is our most popular anti-fatigue mat. It's ability to perform in a variety of indoor environments (from sensitive to harsh) make it a "go-to" solution for indoor commercial and industrial settings where slag, grease and oil, or chemicals are present.

2' x 3' (23" x 32")
3' x 5' (32" x 58")
3' x 12' (32" x 143")
4' x 6' (46" x 70")
4.8' x 8' (58" x 95")

Custom sizes are available in widths of 2' (23"), 3' (32"), 4' (46"), and 4.8' (58") and lengths up to 100'. Please note that mats over 60' will have up to 2 seams.

Please note, mat sizes are approximate as rubber shrinks and expands in conjunction with temperature and time. Tolerable manufacturing size variance is 3-5%.

SURFACE
Material: Nitrile rubber

CUSHION
Material: High-density, closed-cell nitrile/PVC-blended foam

OVERALL MAT THICKNESS: 5/8 inch (0.6250" ) or 7/8 inch (0.8750") depending on the product selected

STANDARDS & TESTING

  • Durometer: 56
  • Compression Deflection:
         5/8" Mat: 40% at 20 psi, 55% at 40 psi
         7/8" Mat: 47% at 20 psi, 62% at 40 psi
  • Certified high-traction by the National Floor Safety Institute (NFSI)
  • Passes flammability standard DOC-FF1-70
  • Passes AATCC test method 134-1996
  • ASTM C1028-96 static coefficient of friction:
         Dry 0.92
         Wet 0.86
  • ESD rating of electrically conductive:
         Surface to surface at 50% relative humidity 2.6 x 10^5 ohms
         Surface to surface at 12% relative humidity 3.0 x 10^5 ohms
  • ASTM D1667 water absorption: 0.01 pounds/foot2 maximum
  • ASTM D1056 temperature use: cold crack -20 degrees F
  • Melt point over 500 degrees F; tested at temperatures up to 1800 degrees F for welding/slag resistance (results available upon request)

Hog Heaven mats can be cleaned by scrubbing with a deck brush (when needed), using detergent with a neutral pH, and rinsing with a hose or pressure washer.  Mats should be laid flat or hung to dry.
